Product Details
＋- Main frame – 2x3” 11-gauge oval tubular steel with a combination of 2x2” round tubing.
- All welded construction by inert-gas MIG welding conforming with all Structural Welding Code-Steel Standards and Specifications.
- Eight-step electrostatically applied powder coat finish.
- Main frame: Platinum Sparkle Accent: Cathedral Gray
- Durable high density pads upholstered in two-tone (Black & Cadet) premium grade, double-stitched naugahyde.
- High density 2” thick rebond urethane foam glued to 1” industrial plywood backing, trimmed and formed to exact fit.
- 1/2” push-pull spring loaded solid steel adjustment pins with ultimate load of 9040 lbs. and 46042 psi sheer strength.
- 1” solid steel pivot axles with non-friction 2” sealed bearings (load rating of 2400 lbs.) internally encased on primary pivots, and oil-impregnated bronze bushings on all secondary pivots.
- 3/4” solid steel 1045 (tgp) polished chrome-plated finish.
- 3/16” and 1/8” USA-Made/Certified EXERFLEX PRO® high performance fitness cable.
- 4-1/2” and 3-1/2” fiberglass-impregnated nylon pulleys with double sealed roller bearings.
- Solid steel, magnetic with ball-end to ensure a tight connection and secure fit. Coiled lanyard helps prevent pin removal and loss.
- All frame bolts and nuts are 3/8” and 1/2” zinc plated.
- Black painted solid steel weight plates with self aligning low friction sleeves.
- Length x Width x Height: 85 x 49 x 84 in/216 x 124 x 213 cm
- Weight: 550 lb/249 kg
